Specifications:
Category Specification Dimensions (L×W×H) 209.98 mm × 40.95 mm × 219.83 mm Product Colour White Hardware Configuration 2.4G Wi-Fi 2×2 (IEEE 802.11be, up to 688 Mbps theoretical max rate) 5G Wi-Fi 2×2 (IEEE 802.11be, up to 2882 Mbps theoretical max rate) Antennas 4× high-gain antennas Heat Dissipation Natural heat dissipation Total Ports 1× 10/100/1000/2500 Mbps WAN/LAN auto-sensing port3× 10/100/1000 Mbps WAN/LAN auto-sensing ports LED Indicator Light Single light System Reset Button ×1 Mesh Networking Button ×1 Power Input Port ×1 Protocol Standards IEEE 802.11a/b/g/n/ac/ax/be, IEEE 802.3/3u/3ab/3bz Wireless Specifications Dual-band 2.4 GHz, 5 GHz Modulation 11b: DSSS: DBPSK, DQPSK, CCK11a/g: OFDM: BPSK, QPSK, 16/64 QAM11n: MIMO-OFDM: BPSK, QPSK, 16/64 QAM11ac: MIMO-OFDM: BPSK to 256 QAM11ax: MIMO-OFDMA: BPSK to 1024 QAM11be: MIMO-OFDMA: BPSK to 4096 QAM Data Rates MCS0–MCS13 (supports 2 streams) Software Specifications Operating System MiWiFi ROM Wi-Fi Encryption WPA-PSK / WPA2-PSK / WPA3-SAE, Wireless access control, SSID hidden, Anti-piggybacking protection Management Applications Web access, Xiaomi Home app (Android, iOS)
